Grues portuaires
Portal Slewing Crane, also called a portal boom crane, is used for loading and unloading operations with a grab or hook at the front of port terminals and open-air stockpiles. It has a strong lifting capacity of tens to thousands of tons and can easily lift various heavy objects. The Portal Slewing Crane is divided into two types: single-arm and four-link according to the boom structure. Its 360° rotating platform and tilting jib system provide a wide range of working ranges, coordinated and adjustable speed of the working mechanism, and efficient operation. The advanced control system can adapt to various harsh environments and different operating scenarios. With a sturdy and durable structure and flexible travel mechanism, it is an ideal solution for operations in ports, shipyards, etc.
L'entraînement électrique adopte la technologie unique de la conversion de fréquence entièrement numérique Ac et du contrôle de la régulation de la vitesse PLC avec un contrôle flexible et une haute précision.
At present, the specifications of the main products are MQ1025, MQ1030, MQ1625, MQ1630, MQ1635, MQ2525, MQ2530, MQ2535, MQ4025, MQ4030, MQ4035 single boom portal crane and four-link portal crane.
The structure of the portal slewing crane can be mainly divided into two major parts, including the upper slewing part and the lower non-slewing part. The upper slewing part includes boom system, herringbone frame, slewing platform, hoisting mechanism, slewing mechanism, luffing mechanism, machine room, and driver's room, etc., while the lower non-slewing part mainly consists of gantry, equalizing beam, running cart, rail clamping device, and windproof anti-tipping device, etc.
| Principaux paramètres techniques | ||||||||
Paramètres de base | Capacité de levage nominale | Crochet (t) | 10 | 16 | 25 | 40 | 60 | 80 |
| Grab(t) | 10 | 16 | 25 | 40 | 40 | 40 | ||
| Min. Working Range (m) | Au-dessus de la surface du rail (m) | 20 | 25 | 25 | 28 | 30 | 35 | |
| Sous la surface du rail (m) | 10 | 10 | 15 | 15 | 18 | 20 | ||
| Portée de travail maximale (m) | 30 | 35 | 35 | 35 | 40 | 45 | ||
| Plage de travail minimale (m) | 8.5 | 8.5 | 9.5 | 11 | 12 | 12 | ||
| Rayon d'orientation de la queue (m) | 6.5 | 7 | 7.5 | 8 | 9 | 9.5 | ||
| Ecartement des rails (m) | 10.5/12 | 10.5/12 | 10.5/12/14 | 10.5/12/14/16 | 12/14/16 | 12/14/16 | ||
| Distance de la base (m) | 10.5/12 | 10.5/12 | 10.5/12/14 | 10.5/12/14 | 12/14/16 | 12/14/16 | ||
| Vitesse | Vitesse de levage | Pleine charge (m/min) | 40 | 40 | 50 | 50 | 40 | 30 |
| Sans charge (m/min) | 60 | 60 | 80 | 80 | 70 | 50 | ||
| Vitesse de guindage (m/min) | 40 | 40 | 50 | 50 | 30 | 30 | ||
| Vitesse d'orientation (r/min) | 1/1.2/1.5 | 1/1.2/1.5 | 1/1.2/1.5 | 1/1.2/1.5 | 0.8/1 | 0.8/1 | ||
| Vitesse de déplacement de la grue (m/min) | 25/30 | 25/30 | 25/30 | 25/30 | 25/30 | 25/30 | ||
| Nombre de roues | 16/20 | 20/24 | 24/32 | 32 | 32/40 | 40 | ||
| Charge maximale sur les roues | 250 | 250 | 250 | 250 | 300 | 300 | ||
| Type de rail | QU80 | QU80 | QU100 | QU100 | QU100 | QU100 | ||
| Alimentation électrique | 3 phases AC 380V 50HZ | |||||||
Portal slewing crane is versatile and applicable to many places, including factories, warehouses, and construction sites. It is suitable for moving materials and equipment, as well as loading and unloading trucks and containers. The portal slewing crane is easily movable, promoting optimal utilization of available space. It offers a flexible and ergonomic solution for diverse lifting needs when a stationary crane is not required. It is also popular in ports, docks, storage yards, and other places to complete the loading, unloading, and transshipping operations of ships and vehicles. lts design, manufacturing, and inspection implement the latest domestic.
